- General Information
- Manufacturer
- ASUS Computer International
- Manufacturer Website Address
- http://www.asus.com/au
- Brand Name
- Asus ROG
- Product Line
- Astral
- Marketing Information
ROG Astral GeForce RTX™ 5090 32GB GDDR7 OC Edition
ROG Astral GeForce RTX™ 5090 32GB GDDR7 OC Edition - the first ROG quad-fan graphics card delivering unprecedented airflow and air pressure for optimal cooling performance
- AI Performance: 3593 AI TOPS
- Powered by the NVIDIA Blackwell architecture and DLSS 4
- OC mode: 2610 MHz (OC mode)/ 2580 MHz (Default mode)
- Quad-fan design boosts air flow and pressure by up to 20%
- Patented vapor chamber with milled heat spreader for lower GPU temperatures
- Phase-change GPU thermal pad ensures optimal heat transfer, lowering GPU temperatures for enhanced performance and reliability
- 3.8-slot design: massive heatsink and fin array optimized for airflow from the four Axial-tech fans
- Secure GPU protection with GPU Guard technology securing four corners of the GPU and GPU bracket ensures stable mounting.
- Full metal diecast shroud, frame backplate, and rear I/O bracketbrace the PCB for rigidity.
- Powerful 80-amp MOSFETs help ensure enhanced performance, stability and higher overclocking potential
- Protective PCB coating guards against moisture, dust, and extreme temperatures.
- Auto-Extreme manufacturing process for precision and reliability
- GPU Tweak III software provides intuitive performance tweaking, advanced thermal controls and system monitoring
ROG Astral GeForce RTX™ 5090 | The Final Frontier
The new ROG Astral family was inspired by the limitless expanse and beauty of the cosmos, and it is a testament to an unending dedication to exploring and defining new frontiers. In that spirit, the ROG Astral GeForce RTX 5090 introduces ROG's first quad-fan graphics card, coupled with a patented vapor chamber, increased heatsink fin density, a phase-change GPU thermal pad, towering default clock speeds, boosted power delivery, and more. These premium innovations - amplified by an eye-catching die-cast frame and metal GPU bracket - combine to deliver absolute performance that can handle even the most demanding gaming scenarios.
NVIDIA Blackwell Architecture
The Ultimate Platform for Gamers and Creators
Fifth-Gen Tensor Cores
Max AI performance with FP4 and DLSS 4
New Streaming Multiprocessors
Optimized for neural shaders
Fourth-Gen Ray Tracing Cores
Built for Mega Geometry
- Product Type
- Graphic Card
- Technical Information
- API Supported
- OpenGL 4.6
- Number of Monitors Supported
- 4
- Features
- Quad-fan Cooler
- Ray Tracing
- Maximum Digital Display Resolution
- 7680 x 4320
- CUDA Cores
- 21760
- AI-powered
- Yes
- Processor & Chipset
- Chipset Manufacturer
- NVIDIA
- Chipset Line
- GeForce
- Chipset Series
- RTX
- Chipset Model
- RTX 5090
- GPU Boost Clock
- 2.61 GHz
- Memory
- Standard Memory
- 32 GB
- Memory Technology
- GDDR7
- Bus Width
- 512 bit
- Interfaces/Ports
- Host Interface
- PCI Express 5.0
- DisplayPort
- Yes
- Number of DisplayPort Outputs
- 3
- HDMI
- Yes
- Number of HDMI Outputs
- 2
- Power Description
- Power Supply Wattage
- 1 kW
- Power Connector
- 1x 16-pin
- Physical Characteristics
- Slot Space Required
- Quad
- Form Factor
- Plug-in Card
- Cooler Type
- Fan Cooler
- Height
- 76 mm
- Width
- 149.3 mm
- Length
- 357.6 mm
- Miscellaneous
- Platform Supported
- PC
